354 kW(474.7 hp) @1,800 rpm
76.9 ton
3.4 ~ 5.2 m³
| Operating Weight | 76.9 ton |
| Bucket Capacity | 3.4 ~ 5.2 m³ |
| Size | Large |
| Emission | – |
| Engine model | Perkins 2506D |
| Rated Power | 354 kW(474.7 hp) @1,800 rpm |
| Max. Torque | 223 kgf·m / 1,400 rpm |
| Main pumps rated flow | 504 ℓ/min |
| Implement circuit | 357 kgf/cm2 |
| Fuel tank | 880 ℓ |
| Hydraulic tank | 435 ℓ |
| DEF/ ADBLUE tank | – ℓ |
| Swing speed | 7.5 rpm |
| Travel speed | 4.8 km/h |
| Max. Traction force | 70,700 kgf |
| Max. gradeability | 35 deg |
| Bucket Digging Force (ISO) | 38,600 kgf |
| Arm Digging Force (ISO) | 29,100 kgf |
| Overall length | 13,165 mm |
| Overall height | 4,865 mm |
| Overall width | 3,810 mm |
| Tail swing radius | 4,100 mm |
| Tumbler distance | 4,730 mm |
| Ground clearance | 830 mm |
| Boom length | 7,700 mm |
| Arm length | 3,550 mm |
| Max. Digging reach | 13,215 mm |
| Max.Digging depth | 8,370 mm |
| Max. Digging Height | 12,000 mm |
| Max. Dumping Height | 8,380 mm |
| Min. Swing radius | 5,730 mm |
