| Operating Weight | 24.6 ton |
| Bucket Capacity | 4.5 m³ |
| Backhoe Bucket Capacity | – m^3 |
| Loader Bucket Capacity | – m^3 |
| Operating capacity | – kg |
| Engine model | QSM11 |
| Travel speed | 39 km/h |
| Tipping load | 20000 kg |
| Overall Length | 9210 mm |
| Overall Width | 3300 mm |
| Overall Height | 6005 mm |
| Wheelbase | 3520 mm |
| Ground clearance | 443 mm |
| Tires | 26.5R25 L3 ★★ |
| Emission | TIER 3 |
| Rated Power | 335hp/2100rpm |
| Emission | TIER 3 |
| Engine model | QSM11 |
| Rated Power | 335hp/2100rpm |
| Max. Torque | 170.7kgf·m/1400rpm |
| Breakout force | 21820 kgf |
| Static Tipping Load (Staight) | 19840 kg |
| Static Tipping Load (Full-Turn) | 17240 kg |
| Bucket Pin Hinge Height(Raise) | 6005 mm |
| Front Speed (Raise) | 5.4 sec |
| Front Speed (Lower) | 3.4 sec |
| Front Speed (Dump) | 1.5 sec |
| Overall Length | 9210 mm |
| Overall Width | 3300 mm |
| Overall Height | 6005 mm |
| Wheelbase | 3520 mm |
| Ground clearance | 443 mm |
| Tires | 26.5R25 L3 ★★ |
| Transport Length | – mm |
| Transport Height | – mm |
| Transport Width | – mm |
| Front Tires | – |
| Rear Tires | – |
The Cummins QSM11 is not just a powerful engine it is one of the most field-proven heavy equipment engines in the world, running in extreme heat, dust, and continuous loading cycles without complaint. At 250 kW (335 HP), the HL775-9 has the reserve power to push through heavy aggregate piles, climb ramps under full load, and maintain peak output during the longest UAE summer shifts. Three selectable operating modes Power, Standard, and Econo let operators tune output to the job, saving fuel when full power is not needed and unleashing it when it is.
Every cubic metre of bucket capacity is a direct productivity multiplier. The HL775-9’s 4.5 m³ bucket means fewer passes per truck load, shorter loading cycles, and higher daily tonnage than smaller payloaders in the UAE market. On a busy quarry or ready-mix plant where truck turnaround drives profitability, this capacity advantage compounds across every hour of operation. Making the HL775-9’s wheel loader price in UAE one of the best long-term investments in your fleet.
Loading loose sand is one thing. Penetrating compacted aggregate stockpiles, dense clay, or crushed rock face requires genuine breakout force. The HL775-9 delivers 20,800 kgf. Enough to bite clean into the hardest material piles common across UAE quarrying and construction operations, filling the bucket completely on the first pass rather than skimming the surface and requiring a second approach.
Truck drivers, batching plant operators, and site managers all measure productivity by how long the loader keeps them waiting. The HL775-9’s 1.5-second dump cycle time is among the fastest in its class, meaning the bucket empties, returns, and is back at the face before the next truck has fully positioned itself. On sites where truck loading is the throughput bottleneck, this speed directly increases daily output.
The fully automatic 4-speed transmission with manual, light, normal, and heavy shift modes eliminates the gear-change workload from the operator. It selects the right ratio for each phase. Approaching the pile, pushing in, reversing, and travelling automatically. The result is smoother machine movement, less drivetrain wear, and operators who arrive at the end of a long shift less fatigued and more productive throughout.
Heavy-duty axles with self-adjusting wet disc brakes, a long-life cooling system designed to resist thermal shock and vibration, and dust-sealed components give the HL775-9 the structural resilience to operate continuously in the UAE’s 50°C summer heat and abrasive sandy environments. Backed by Al Shirawi Machinery’s UAE-wide service network, genuine Hyundai parts, and a factory toll-free after-sales line, your payloader investment in UAE is protected for years.
When you search for a wheel loader for sale in Dubai or compare payloader prices in UAE, the dealer you choose matters as much as the machine. Al Shirawi Machinery is the exclusive authorised Hyundai Construction Equipment dealer in the UAE. The only company that can offer you a genuine factory-warranted Hyundai HL775-9 with full UAE after-sales support.
Factory-certified, factory-backed, and factory-supported. Every HL775-9 sold by Al Shirawi comes with a complete Hyundai factory warranty, certified pre-delivery inspection, and direct access to Hyundai’s global technical support. No grey-market machines, no voided warranties, no compromise.
As the manufacturer’s direct representative, Al Shirawi provides the fairest payloader price in UAE with no inflated distributor margins. Fleet buyers and single-machine purchasers both receive transparent pricing, and our team will walk you through every cost so there are no surprises after the sale.
From individual machine purchases to multi-unit fleet deals, Al Shirawi structures payment terms that fit your project cash flow. Whether you are a single contractor buying your first loader for sale in Dubai or a large fleet operator renewing your payloaders across the GCC, talk to our team about options that work for you.
Critical wear parts, filters, hydraulic components, and tyres are stocked at our Al Quoz, Dubai Investment Park, and Abu Dhabi Musaffah branches. When a part is needed, it is available keeping your wheel loader productive and your projects on schedule.
The HL775-9 is purpose-built for operations where volume, speed, and reliability are non-negotiable. UAE and GCC industries that rely on this machine daily include:
| Requirement | Mid-Range Loader | Hyundai HL775-9 ✦ Best Option | Larger Class Alternative |
|---|---|---|---|
| Operating Weight | 17.9 ton | 24.6 ton | ~28–32 ton |
| Engine Output | 160 kW / 214 HP | 250 kW / 335 HP | ~280–320 kW |
| Bucket Capacity | 3.3 m³ | 4.5 m³ | ~5.0–6.0 m³ |
| Tipping Load | 13,840 kg | 20,000 kg | ~22,000–28,000 kg |
| Breakout Force | – | 20,800 kgf | Higher |
| Dump Cycle Time | 3.1 sec | 1.5 sec | ~1.5–2.0 sec |
| Transmission | Standard | 4-Speed Automatic, 4 Modes | Automatic |
| Operating Modes | Standard | Power / Standard / Econo | Varies |
| Authorised UAE Dealer | ✔ Yes — Al Shirawi | ✔ Yes — Al Shirawi | Varies |
| Warranty | ✔ Full Factory Warranty | ✔ Full Factory Warranty | Brand-specific |
| Spare Parts Availability (UAE) | ✔ Genuine Hyundai Parts | ✔ Genuine Hyundai Parts | Brand-specific |
| After-Sales Support Hotline | ✔ 800HDH (800434) | ✔ 800HDH (800434) | Varies |
The HL760-9 is the right machine for busy construction sites and mid-scale material handling. The HL775-9 is the right machine when nothing less than maximum output will do. Both are available from Al Shirawi Machinery the UAE’s only authorised Hyundai dealer.
