178hp/2000rpm
20.5 ton
0.8 m³
| Operating Weight | 20.5 ton |
| Bucket Capacity | 0.8 m³ |
| Size | – |
| Emission | TIER 2 |
| Engine model | HYUNDAI HM5.9 |
| Rated Power | 178hp/2000rpm |
| Max. Torque | 72.2kgf·m/1500rpm |
| Main pumps rated flow | 2×192 ℓ/min |
| Implement circuit | 350 kgf/cm2 |
| Fuel tank | 310 ℓ |
| Hydraulic tank | 165 ℓ |
| DEF/ ADBLUE tank | – ℓ |
| Swing speed | 10.5 rpm |
| Travel speed | 30 km/h |
| Max. Traction force | 11900 kgf |
| Max. gradeability | 34 deg |
| Bucket Digging Force (ISO) | 16830 kgf |
| Arm Digging Force (ISO) | 11830 kgf |
| Overall length | 9500 mm |
| Overall height | 3150 mm |
| Overall width | 3770 mm |
| Tail swing radius | 2800 mm |
| Tumbler distance | 2800 mm |
| Ground clearance | 345 mm |
| Boom length | 5650 mm |
| Arm length | 2920 mm |
| Max. Digging reach | 9960 mm |
| Max.Digging depth | 6380 mm |
| Max. Digging Height | 10000 mm |
| Max. Dumping Height | 7160 mm |
| Min. Swing radius | 3580 mm |
