| Operating Weight | 18.5 ton |
| Bucket Capacity | 0.89 m³ |
| Size | – |
| Emission | TIER 2 |
| Engine model | MITSUBISHI S6S-DT |
| Rated Power | 126hp/2100rpm |
| Max. Torque | 42.5kgf·m/1400rpm |
| Main pumps rated flow | 2×172 ℓ/min |
| Implement circuit | 350 kgf/cm2 |
| Fuel tank | 270 ℓ |
| Hydraulic tank | 124 ℓ |
| DEF/ ADBLUE tank | – ℓ |
| Swing speed | 11 rpm |
| Travel speed | 30 km/h |
| Max. Traction force | 11600 kgf |
| Max. gradeability | 35 deg |
| Bucket Digging Force (ISO) | 13680 kgf |
| Arm Digging Force (ISO) | 8890 kgf |
| Overall length | 8730 mm |
| Overall height | 3940 mm |
| Overall width | 2500 mm |
| Tail swing radius | – mm |
| Tumbler distance | – mm |
| Ground clearance | – mm |
| Boom length | 5100 mm |
| Arm length | 2600 mm |
| Max. Digging reach | 9020 mm |
| Max.Digging depth | 5820 mm |
| Max. Digging Height | 9070 mm |
| Max. Dumping Height | 6460 mm |
| Min. Swing radius | 3170 mm |
