113hp/2.1rpm
13.7 ton
0.58 m³
| Operating Weight | 13.7 ton |
| Bucket Capacity | 0.58 m³ |
| Size | – |
| Emission | TIER 2 |
| Engine model | CUMMINS B3.9C |
| Rated Power | 113hp/2.1rpm |
| Max. Torque | 45.6kgf·m/1500rpm |
| Main pumps rated flow | 2×130 ℓ/min |
| Implement circuit | 350 kgf/cm2 |
| Fuel tank | 270 ℓ |
| Hydraulic tank | 124 ℓ |
| DEF/ ADBLUE tank | – ℓ |
| Swing speed | 12.9 rpm |
| Travel speed | 30 km/h |
| Max. Traction force | 8500 kgf |
| Max. gradeability | 35 deg |
| Bucket Digging Force (ISO) | 11290 kgf |
| Arm Digging Force (ISO) | 8580 kgf |
| Overall length | 7820 mm |
| Overall height | 3500 mm |
| Overall width | 2500 mm |
| Tail swing radius | – mm |
| Tumbler distance | – mm |
| Ground clearance | – mm |
| Boom length | 4600 mm |
| Arm length | 2100 mm |
| Max. Digging reach | 7920 mm |
| Max.Digging depth | 4850 mm |
| Max. Digging Height | 8470 mm |
| Max. Dumping Height | 6040 mm |
| Min. Swing radius | 2670 mm |
